Rotation Direction: Left or Right
Wire Rope Diameter: 3 MM~190 MM
Rope capacity: 1000M-10000M
Processing equipment: CNC machining center
Durm Type: LBS spooling system - based on the unique geometry of the drum grooving
Product structure:
Integral rope groove drum: rope drums with grooves cut directly into them (with or without bolted or welded flanges, as required).Winch drum with flange, the LBS groove is cut directly into the body of the drum, according to customers’ requirements, the flanges are either welded or screw-bolted. groove geometry is determined by rope construction, diameter and length, and by application. the drum has the required mounting dimensions for the actual operating conditions.
Product application:
1. Crane machinery: The bridge lifting machine, Tower crane, Gantry crane,Crawler crane winch
2. The oil field industry: Oil drilling rig, Petroleum tractor hoist, Petroleum workover rig, Trailermounted pumping unit winch , Logging winch, etc
3. The construction machinery: Building wipe wall winch, hoist, Windlass winch
4.Offshore Marine machinery: Offshore petroleum crane winch, Mooring winch, Traction winch, Man-riding winch, Anchor winch, Hydrologic winch
5. Mining winch: Dispatching winch, Prop-pulling winch,Sinking winch, etc
6. Engineering machinery: Cable winch, Tower crane, Piling machine, Hydraulic winch
Product material:
1. carbon structural steel: Q235A/B/C/D/E SS400 A36 SM400 St37-2 S235J...
2. low alloy high strength steel: Q345A/B/C/D/E Q390 Q420 Q460 15GrMo 20GrMo 12GrMoVNi...
3. alloy structural steel: 20Mn2 40Mn2 15Cr 30Cr 20CrMnMo 20CrNi...
4. polymer materials, fiber materials and polyamide nylon materials.
5. stainless steel materials, aluminum materials, etc.
Product advantage:
Compared with cordless groove (smooth) drum and helical groove drum, LBS grooved drum has obvious advantages in multilayer spooling. It can be widely used in the heavy lifting and compact working conditions.
LBS grooved winch drum advantage:
- Each one circle layer of the grooved drum has two parallel groove section and two groove section
- Make wire rope spooling more smooth and uniform distribution of load between each layer
- Prevent cross &mess in rope spooling working happening
- Lower the rope damage, extend the rope life
