Why you should choose us:
Our factory mainly produce the series winch ,LBS groove winch ,LBS groove drum ,LBS groove sleeve .We have our own brand patent LBS that award by goverment .That LBS groove design can more advantage for you especially more years using later ,no need to chage the whole winch only to replace the drum sleeve or the drum that can make your save time and cost.
Product Feature:
1) Two-or three-stage planetary gearboxes, smooth operation and reasonable structure.
2) High efficiency of starting and transmissing, low energy consumption, reliable operation and long service life.
3) Highly efficient, constant operating torque motor.
4) Smooth running over the entire speed range.
5) Axial fixed or variable hydraulic motor with long life operating.
6) Mounting frame is available on request.
7) Low noise operation.
Technical reference:( the parameter can be design new as requirement and working condition)
| Model | Frirst layer Pull force(T) | Drum bottom diameter | Layer | Rope capaticty(mm) | Diameter of steel cable(mm) | Model of power |
| LBSOF6-10 | 1 | 7-12 | 305 | 4 | 160 | 15 | XH2-420 D51 |
| LBSOF6-20 | 2 | 7-28 | 380 | 4 | 180 | 18 | XH3-900 D240 101 |
| LBSOF6-30 | 3 | 6-25 | 470 | 4 | 250 | 24 | XH5-1800 D240101 |
| LBSOF6-40 | 4 | 10-23 | 470 | 4 | 280 | 30 | XH6-2000 D240 101 |
| LBS0F6-50 | 5 | 10-25 | 600 | 4 | 320 | 30 | XH6-3000 D240101 |
| LBSOF6-100 | 10 | 15-30 | 640 | 8 | 600 | 38 | XH7-4300 D240101 |
Product specification:
Custom-made (according to actual )
The winches consist of hydraulic motor with brake, planetary gearbox, drum and frame.
Our service:
1. Top quality with competitive price.
2. Compact structure and reasonable design
3. Safe and reliable function.
4. Highly efficient, constant operating torque motor.
5. Smooth running over the entire speed range.
6. Reliable operation with little noise
Company profile:
Our factory mainly in the service of hoisting machinery, Marine machinery, petroleum machinery, hydraulic machinery, engineering machinery and other industries, the main products are oil drilling rig, workover rig, drifting machine, trailermounted pumping unit winch (The main drum is used LBS grooved drum) and oil equipment accessories.
Product Tags:
|
|
Fully Machined Offshore Winch Hydraulic Traction Hoist Images
|
