Product name:windlass ,mooring winch ,electric winch
Our company brief intruduction:
Shijiazhuang JunZhong Machinery Manufacturing Co., Ltd. specializing in the production of double grooved drum (reel). Jun zhong seek the quality firstly and has its own brand LBS. with introduction of domestic and foreign advanced technology and experience , we are now strong in the multi-layers rope grooved drum area and awarded patent by country having a high reputation in that area.
Technical parameters : can be design to meet requirement and working condition
| No: | Rated load (KN) | Rope diameter (MM) | Rope capacity (M) | Rated speed (M/min) | Motor power (KW) |
| 1 | 200 | 30 | 500 | 7.5 | 55 |
| 2 | 250 | 32 | 550 | 7.5 | 75 |
| 3 | 400 | 36 | 600 | 7.5 | 90 |
| 4 | 500 | 52 | 700 | 7.5 | 110 |
| 5 | 650 | 54 | 750 | 5 | 110 |
| 6 | 800 | 58 | 1100 | 5 | 132 |
| 7 | 1200 | 64 | 1100 | 5 | 180 |
| 8 | 1400 | 70 | 1300 | 5 | 220 |
| 9 | 1600 | 82 | 1300 | 4 | 220 |
| 10 | 2000 | 90 | 1500 | 4 | 250 |
| 11 | 2500 | 102 | 1800 | 4 | 300 |
| 12 | 3000 | 110 | 1800 | 4 | 360 |
Application:
It is widely used in port, workshop, warehouse, construction and many kinds producing-line, so is necessary equipment for lifting goods, raising labor efficiency, improving working conditions.
Features:
1. Our products have the advantages of compact structure, light weight, safe and easy to operate.
2. Our products are used for general lifting, hauling and other works in marine deck machinery, harbor, petroleum, drill machine, engineering machinery, mining, geological exploration and construction machinery and etc.
3. Products are designed and manufactured according to API Spec 7K “Specification for Drilling Equipment”.
4. High starting& working efficiency
5. Reliable operation with little noise
Product advantage:
Our factory mainly in the service of hoisting machinery, Marine machinery, petroleum machinery, hydraulic machinery, engineering machinery and other industries, the main products are oil drilling rig, workover rig, drifting machine, trailermounted pumping unit winch (The main drum is used LBS grooved drum) and oil equipment accessories.
-
Top quality with competitive price.
-
Safe and reliable function.
-
Highly efficient, constant operating torque motor.
-
Smooth running over the entire speed range.
......
